Controls
APOLLO Wi-Fi Fan Coil Thermostat
AP-TH
Homeowners can buy directly at mbtek.com. Installers, contractors and other trade customers: use the contact form, email or phone. info@apolloheatpumps.com · 1-888-301-0737
Image 1 of 14Product overview
APOLLO Wi-Fi Fan Coil Thermostat
Wi-Fi fan coil thermostat for 2-pipe and 4-pipe FCU systems, combining touchscreen control, remote access, and advanced fan or valve modulation for residential and commercial comfort control.
Key Benefits
- Keyword-focused FCU control for fan coil thermostat searches and 2-pipe or 4-pipe applications
- Flexible power options with 12–24 V AC/DC or 110–240 V AC
- 3.5" color touch screen with adaptive brightness and 4 access levels
- Wi-Fi remote access with smart monitoring, GEO-fence automation, and multilingual UI support
- Advanced output control with 3-speed fan, 0-10VDC fan or valve control, and 6-way motor valve support
- Environmental awareness from humidity sensing and external sensor support for remote room, outdoor, pipe, or slab use
Specifications
- Application: Fan coil thermostat for 2-pipe or 4-pipe FCU systems
- Power Options: 12–24 V AC/DC or 110–240 V AC
- Fan Control: 3-speed fan plus 0-10VDC fan or valve control
- Valve Control: 6-way 0-10VDC motor valve control for chilled and heated water loops
- Included Sensor: Additional 20 ft sensor for remote room, outdoor, pipe aquastat, or slab
- Modes: Heat, cool, ventilation, dehumidification, humidification, and auto
- Programming: 5/2, 7-day, and 24-hour scheduling with daylight-saving sync
Replace 120V Honeywell T6570, T6069, T6169, TB6575A, TB6575B, TB6575A1000, T6575D, T6575C, T6574B
Replace 12 to 24VAC/DC Honeywell T8570, TB8575A, TB8575A1000, T8574B, T8575C, T8575D
Replace 12 to 24VAC/DC Coleman Rv Camper Mach Thermostat 7330G3351, 6636-3441, 7330F3852, 8330-3362, 9430-3372
Models and variants
| Model | Available attributes |
|---|---|
| AP-TH-4-12/24V | Electrical Supply: 12–24 V AC/DC |
| AP-THE-FCU-120-240VAC | Electrical Supply: 120–240 V AC/DC |
Specifications
| Application | Wall, floor, concealed, commercial, and ceiling fan coils. Heat and cool valves, 3-speed or 0–10 V fan. Ceiling damper output is 0–10 V DC. |
|---|---|
| Display | 3.5 in color touchscreen |
| Power | 12–24 V AC/DC or 110–240 V AC |
| Built-in sensors | Temperature, humidity, and ambient light |
| External sensor | 20 ft sensor included |
| Temperature limit | 32–210 °F (0–99 °C) |
| Modes | Heat, Cool, Vent, Dehumidify, Auto |
| Fan | 3-speed or 0–10 V DC, 30–100% |
| Outputs | Normally open relays; 0–10 V DC for fan, valve, and damper |
| Connectivity | Wi-Fi, app, MQTT, BACnet, Google Home |
| Scheduling | Schedule, hold, and holiday |
| Languages | 7 |
| Size | 4 1/4 × 3 1/2 × 1 1/4 in |
- Application
- Wall, floor, concealed, commercial, and ceiling fan coils. Heat and cool valves, 3-speed or 0–10 V fan. Ceiling damper output is 0–10 V DC.
- Display
- 3.5 in color touchscreen
- Power
- 12–24 V AC/DC or 110–240 V AC
- Built-in sensors
- Temperature, humidity, and ambient light
- External sensor
- 20 ft sensor included
- Temperature limit
- 32–210 °F (0–99 °C)
- Modes
- Heat, Cool, Vent, Dehumidify, Auto
- Fan
- 3-speed or 0–10 V DC, 30–100%
- Outputs
- Normally open relays; 0–10 V DC for fan, valve, and damper
- Connectivity
- Wi-Fi, app, MQTT, BACnet, Google Home
- Scheduling
- Schedule, hold, and holiday
- Languages
- 7
- Size
- 4 1/4 × 3 1/2 × 1 1/4 in
